Our Work Speaks for Itself

Gallery

Machined parts and shop-floor photos from Turlock: milling, turning, inspection, and finished components. Click any photo for the full-size view.

Plate Work on the Haas VMC — Plate Work on the Haas VMCAluminum plates clamped to the table of a Haas vertical machining center for face and profile milling.

CNC Milling — CNC MillingHigh-pressure coolant and carbide end mills: the everyday reality of CNC milling in aluminum and steel.

Turned Stainless Bushings — Turned Stainless BushingsA production lot of turned stainless bushings, faced and chamfered, ready for inspection.

Cross-Drilling a Stainless Shaft — Cross-Drilling a Stainless ShaftDrilling a cross-hole in a stainless shaft on the vertical mill, held in a vise for true position.

CNC Turning — CNC TurningCNC turning produces shafts, spacers, fittings and bushings to tight concentricity, one of our core processes.

Inspection on the Granite Plate — Inspection on the Granite PlateProbing a machined stainless frame on the granite surface plate to verify hole location and flatness.

Aluminum Mounting Bracket — Aluminum Mounting BracketA four-corner aluminum bracket with counterbores and a center bore, machined complete in one vise setup.

Finished Sample Parts — Finished Sample PartsFinished parts laser-marked with the C&W logo: a splined hub, a lightweight grid plate, a slotted block and a ground blade.

Stainless Finned Hub with Integral Sprocket — Stainless Finned Hub with Integral SprocketA stainless steel hub with machined cooling fins and an integral sprocket, turned and then milled on the 4th axis.

Mechanical Design in CAD — Mechanical Design in CADOur mechanical design service: 3D modeling, engineering drawings and FEA in SolidWorks before anything is cut.

Machining Center Setup — Machining Center SetupMulti-vise setups run several parts per cycle for consistent, repeatable production.

A36 Steel Mold Assembly — A36 Steel Mold AssemblyA mold assembly machined from solid A36 steel: deep pocket, stepped flanges and bolt patterns on every face.

Want your part in the next batch?

Send the model and drawing — we respond within one business day.

Request a Quote Download Certifications
